GENERAL INFORMATION
EAN/UPC – 8435436112485
Subfamily – Box
Product sheet
AEC (Annual energy consumption) (kWh/year) – 102,5
EEI class (energy efficiency class) – C
FDE (fluid dynamic efficiency) – 16,3
FDE class (fluid dynamic efficiency class) – D
LE (light efficiency) (lux/W) – 36
LE class (light efficiency class) – A
GFE (grease filtering efficiency) – 88,5
GFE class (grease filtering efficiency class) – B
Airflow in normal mode MIN (m3/h) – 385
Airflow in normal mode MAX (m3/h) – 645
Acoustic power in normal mode MIN (dB) – 56
Acoustic power in normal mode MAX (dB) – 70
Po (energy consumption in off mode) (W) – 0
Ps (energy consumption in standby mode) (W) – 0
Integration directive EU 66/2014
ƒ (time increase factor) – 1,4
EEI (Energy Efficiency Index) – 83,4
QBEP (maximum efficiency at air flow point) (m3/h) – 375,3
PBEP (maximum efficiency at pressure point) (Pa) – 295
WBEP (power consumption at maximum efficiency) (W) – 188,8
WL (nominal power lighting system) (W) – 7
EMIDDLE (Average illuminance on the cooking surface) (lux) – 252
External Dimensions
Width (mm) – 600
Depth (mm) – 500
Maximum total height (mm) – 1045
Minimum total height (mm) – 730
Diamètre de sortie (mm) – 125
Characteristic
Motor quantity – 1
Motor model – TA
Maximum pressure (Pa) – 430
Filter technology – Aluminium mesh
Control technology – Mechanical push button
Booster –
Power levels – 3
Timer –
Filter saturation indicator –
Charcoal filter replacement indicator –
Dimmer function –
Connectivity –
Remote control –
Display –
Lighting
Light model – ECOLED
Ray technology – LED
Installation
Minimum distance to electric plate (mm) – 550
Minimum distance to gas plate (mm) – 650
Recirculation option – √
Charcoal filter –
Back draught shutter – Included
Inner shield –
Electrical connection
Nominal voltage (V) – 220-240
Nominal frequency (Hz) – 50/60
Nominal input power (W) – 277
Electric shock protection – Class II
Power cord length (m) – 1,5
Accessories
Upper decorative duct extension – 2861301
White decorative duct – No
Black decorative duct – No
Island tube booster – No
Back draught shutter – Included
MAX PRO Metal filter – 2800917
Activated charcoal filter – 2859391
Noiseless flexible duct – 2893002
Recirculation kit – 2894001
